PLANNING Palo Alto I-Box CORNER FRAME SIDES D.586 ROSSPIECES / CORNER FRAME SIDE PANEL SUPPORTS D.586 CORNER MODULE

For reductions, see the chapter on Reductions and Supplements page 545. N.B. FOR CORRECT USE SEE TECHNICAL NOTES PAGE - TYPES: CROSSPIECES / FRAME SIDE PANEL SUPPORTS.
APPLICABLE ON REQUEST VERTICAL LED LIGHT see chapter on zaffiro lights pag. 417.

W.15mm. W.31mm. W.38mm.
fixed on the frame movable on the frame movable on the beginning /
Beginning / end frame side panel WITH GLASS central with glass beginning / end with frame end / central frame without glass
Th.38mm. D586mm. Additional height-adjustable
with 2 fixed crosspieces W.38mm. for base/cover crosspieces
plus 1 height-adjustable crosspiece W.31mm. for internal shelf
for shelf/drawer units H.2262 H.2422 H.2582 H.2742 H.2902 drawer units and accessories

CODE TI6V TI7V TI8V TI9V TIOV CODE TR15 TR31 TR38
GUN METAL / DARK BRONZE - CATEGORY A GLASS 1.438 1.460 1.485 1.522 1.821 GUN METAL / DARK BRONZE 153 85 85
GUN METAL / DARK BRONZE - CATEGORY C GLASS 1.760 1.786 1.812 1.855 2.184
GUN METAL / DARK BRONZE - CATEGORY LUX GLASS 2.113 2.144 2.175 2.226 2.621

Beginning / end frame side panel WITHOUT
GLASS SINGLE W.15mm SINGLE W.31mm DOUBLE W.38mm
Th.38mm. D.586mm. fixed moveable CENTRAL
with 2 fixed crosspieces W.38mm. for base / cover moveable
plus 1 height-adjustable crosspiece W.38mm. Supports
for shelf / drawer units H.2262 H.2422 H.2582 H.2742 H.2902 for glass shelves
CODE TI6 TI7 TI8 TI9 TIO CODE REF15SX REF15DX REF31SX REF31DX REF38
GUN METAL / DARK BRONZE 978 992 1.003 1.030 1.181 GUN METAL / DARK BRONZE 14 14 22 22 23

Central frame side panel WITH GLASS SINGLE W.15mm SINGLE W.31mm DOUBLE W.38mm
Th.38mm. D.586mm. fixed moveable CENTRAL
with 2 fixed crosspieces W.38mm. for base / cover moveable
plus 1 height-adjustable crosspiece W. 15mm. Supports
for shelf / drawer units H.2262 H.2422 H.2582 H.2742 H.2902 for inclined shoe rack shelves
CODE TC6V TC7V TC8V TC9V TCOV CODE REF15PSX REF15PDX REF31PSX REF31PDX REF38P
GUN METAL / DARK BRONZE - CATEGORY A GLASS 2.141 2.168 2.205 2.245 2.548 GUN METAL / DARK BRONZE 18 18 26 26 27
GUN METAL / DARK BRONZE - CATEGORY C GLASS 2.592 2.621 2.660 2.701 3.019
GUN METAL / DARK BRONZE - CATEGORY LUX GLASS 2.925 2.958 2.999 3.046 3.396

Central frame side panel WITHOUT GLASS
Th.38mm. D.586mm.
with 2 fixed crosspieces W.38mm. for base / cover
plus 1 height-adjustable crosspiece W.38mm.
for shelf / drawer units H.2262 H.2422 H.2582 H.2742 H.2902
CODE TC6 TC7 TC8 TC9 TC0
GUN METAL / DARK BRONZE 978 992 1.003 1.030 1.181
