HINGED Palo Alto I-Box FRAME SIDE PANELS D.380 CROSSPIECES / FRAME SIDE PANEL SUPPORTS D.380 STRUCTURAL ELEMENTS

For reductions see chapter on Reductions and Supplements pag. 545. N.B. FOR CORRECT USE SEE TECHNICAL NOTES PAGE - TYPES: CROSSPIECES/FRAME SIDE PANEL SUPPORTS.
APPLICABLE ON REQUEST VERTICAL LED LIGHT see chapter on zaffiro lights pag. 417.

W.15mm. W.31mm. W.38mm.
fixed to frame movable on the frame movable on the beginning/
Beginning / end frame side panel WITH GLASS central with glass beginning/end with frame end/central frame without glass
Th.38mm. D.380mm. Additional height-adjustable
with 2 fixed crosspieces W.38mm. for base / cover crosspieces
plus 1 height-adjustable crosspiece W.31mm. for internal shelf
for shelf / drawer units H.1942 H.2262 H.2422 H.2582 H.2742 H.2902 drawer units and accessories

CODE TI35V TI36V TI37V TI38V TI39V TI30V CODE TR315 TR331 TR338
GUN METAL / DARK BRONZE - CATEGORY A GLASS 1.426 1.438 1.460 1.485 1.522 1.821 GUN METAL / DARK BRONZE 153 86 86
GUN METAL / DARK BRONZE - CATEGORY C GLASS 1.751 1.760 1.786 1.812 1.855 2.184
GUN METAL / DARK BRONZE - CATEGORY LUX GLASS 2.098 2.113 2.144 2.175 2.226 2.621

Beginning / end frame side panel WITHOUT
GLASS SINGLE W.15mm SINGLE W.31mm DOUBLE W.38mm
Th.38mm. D.380mm. fixed moveable CENTRAL
with 2 fixed crosspieces W.38mm. for base / cover moveable
plus 1 height-adjustable crosspiece W.38mm. Supports
for shelf / drawer units H.1942 H.2262 H.2422 H.2582 H.2742 H.2902 for glass shelves
CODE TI35 TI36 TI37 TI38 TI39 TI30 CODE REF15SX REF15DX REF31SX REF31DX REF38
GUN METAL / DARK BRONZE 965 978 992 1.003 1.030 1.181 GUN METAL / DARK BRONZE 14 14 22 22 23

Central frame side panel WITH GLASS SINGLE W.15mm SINGLE W.31mm DOUBLE W.38mm
Th.38mm. D.380mm. fixed moveable CENTRAL
with 2 fixed crosspieces W.38mm. for base / cover moveable
plus 1 height-adjustable crosspiece W.15mm. Supports
for shelf / drawer units H.1942 H.2262 H.2422 H.2582 H.2742 H.2902 for inclined shoe rack shelves
CODE TC35V TC36V TC37V TC38V TC39V TC30V CODE REF15PSX REF15PDX REF31PSX REF31PDX REF38P
GUN METAL / DARK BRONZE - CATEGORY A GLASS 2.122 2.141 2.168 2.205 2.245 2.548 GUN METAL / DARK BRONZE 18 18 26 26 27
GUN METAL / DARK BRONZE - CATEGORY C GLASS 2.571 2.592 2.621 2.660 2.701 3.019
GUN METAL / DARK BRONZE - CATEGORY LUX GLASS 2.903 2.925 2.958 2.999 3.046 3.396

Central frame side panel WITHOUT GLASS
Th.38mm. D.380mm.
with 2 fixed crosspieces W.38mm. for base / cover
plus 1 height-adjustable crosspiece W.38mm.
for shelf / drawer units H.1942 H.2262 H.2422 H.2582 H.2742 H.2902
CODE TC35 TC36 TC37 TC38 TC39 TC30
GUN METAL / DARK BRONZE 965 978 992 1.003 1.030 1.181
