MILLIMETRICA walk-in wardrobe SHOE RACKS D.380 CORNER TYPES TECHNICAL NOTES
Available for WOOD and FRAME side panels. CORNER SOLUTIONS, WITHOUT BACK
WOOD side panels 10 10
Hole Ø 3mm. TO DRAWING, 80mm. centres, included in the price. A
Hole Ø 3mm. FITTING holes, 80mm. centres, supplement for module € 65. 10
Hole Ø 3mm. at non-standard distances on wood sides, supplement for module € 130.
380 546
380
380
380 B
380
380
2897
2577 2737 10
2257 2417 A
1937 10 side
panel
corner
B
CORNER SOLUTIONS, WITH BACK
10 33
SHOE RACK SHELF ARRANGEMENT C D
33
380 380 546
522 602 762 922
80 module for standard
376
376
80
1082 1242 297 60
9°
Wood side Aluminium C D
frame side
33 33
back
Th.19mm.
10 back profile 33
358 359
