WALL-MOUNTED BRIDGE D.586

WALL-MOUNTED BRIDGE
A series of containers alongside one another and joined by a support bar underneath, and an upper supporting cross-bar made of aluminium.
Comes with FISCHER Ø 6mm. x 50 TBS anchors for connecting to concrete, hollow brick, or solid brick walls.
The containers are made with reinforced bases and tops, and have an upper profile for connecting to the upper bar.
The loadbearing capacity of the containers is 80 kg plus their own weight (ICQ tests done on a container W.960xD586xH1280 mm), and relates to the type of
wall the bridge is mounted on.
Add the price of the handle required.
Each pair of swinging doors is equipped with just one handle on the right-hand door.
Handles can be installed on both doors upon request, see handles chapter on page 31
ZAFFIRO APPLICABLE ON REQUEST HORIZONTAL LED LIGHT see chapter on zaffiro lights pag. 417.
The compartment below can be finished using a wood finishing back (optional).

8 586 22
480 960 1120
8
38 2 30
bar and profile 568
at the top

Corner container

1120 960 22 586 8
8

568
1120

container fixing and 636
restraining screws
fixed door for corner door 155°
W.636mm.
38 W.476mm.
2
lower profile LED light
for support
