HINGED Palo Alto I-Box WOOD SIDE PANELS D.586 SIDE PANELS / UPPER SIDE PANELS IN WOOD D.586 STRUCTURAL ELEMENTS

For reductions see chapter on Reductions and Supplements pag. 545. For reductions see chapter on Reductions and Supplements pag. 545.
APPLICABLE ON REQUEST VERTICAL LED LIGHT see chapter on zaffiro lights pag. 417. APPLICABLE ON REQUEST VERTICAL LED LIGHT see chapter on zaffiro lights pag. 417.

Hole Ø 3mm. TO DRAWING, 80mm. centres, included in the price. Hole Ø 3mm. TO DRAWING, 80mm. centres, included in the price.
Hole Ø 3mm. FITTING holes, 80mm. centres, supplement for module 65 €. Hole Ø 3mm. FITTING holes, 80mm. centres, supplement for module 65 €.
Hole Ø 3mm. at non-standard distances on wood sides, supplement for module 130 €. Hole Ø 3mm. at non-standard distances on wood sides, supplement for module 130 €.

Beginning/end panel Central side panel
Th.19mm. - D.586mm. H.1942 H.2262 H.2422 H.2582 H.2742 H.2902 Th.38mm. - D.586mm H.1942 H.2262 H.2422 H.2582 H.2742 H.2902
CODE FT5 FT6 FT7 FT8 FT9 FT0 CODE FC5 FC6 FC7 FC8 FC9 FC0
MELAMINE 196 203 209 214 222 277 MELAMINE 262 269 280 292 303 362
MATT LACQUER / MELAMINE INTERNAL STRUCTURE 295 307 320 332 342 562 MATT LACQUER 506 520 537 651 688 795
MATT LACQUER / MATT LACQUER INTERNAL STRUCTURE 394 409 431 446 466 584
GLOSSY LACQUER / MELAMINE INTERNAL STRUCTURE 548 573 604 637 667 948
GLOSSY LACQUER / MATT LACQUER INTERNAL STRUCTURE 656 677 715 751 787 1.032

Beginning/end panel Upper side panel
Th.38mm. - D.586mm. H.1942 H.2262 H.2422 H.2582 H.2742 H.2902 Th.19mm. - D.606mm H.1942 H.2262 H.2422 H.2582 H.2742 H.2902 *
CODE FT58 FT68 FT78 FT88 FT98 FT08 CODE FV5 FV6 FV7 FV8 FV9 FV0
MELAMINE 262 269 280 292 303 362 MELAMINE 246 267 286 299 320 352
MATT LACQUER / MELAMINE INTERNAL STRUCTURE 362 373 390 409 426 664 MATT LACQUER 330 358 381 394 426 468
MATT LACQUER / MATT LACQUER INTERNAL STRUCTURE 506 520 537 651 688 795 GLOSSY LACQUER 859 913 967 1.019 1.139 1.255
GLOSSY LACQUER / MELAMINE INTERNAL STRUCTURE 617 641 675 712 748 1.000 WOOD 572 603 637 670 719 794
GLOSSY LACQUER / MATT LACQUER INTERNAL STRUCTURE 704 726 766 806 847 1.100

174 Prices listed are for standard colours. For other colours add 15% to the price Prices listed are for standard colours. For other colours add 15% to the price 175
